Stainless Steel 304/304L/304H Long Radius Bends
Introduction
Stainless Steel 304 Long Radius Bend Supplier, ASTM A403 Stainless Steel Long Radius Bend, 304L SS Welded Pipe Bend, Stainless Steel 321H Piggable Bends Exporter in India.
ANSI B 16.9 SS Long Radius Pipe Bend, Stainless Steel DIN 1.4301 U Pipe Bend, DIN 1.4306 SS 304H J Pipe Bends, Stainless Steel UNS S30400 / S30403 / S30409 Long Radius Bend Fittings in India.
Further Reading
Stainless Steel 304 / 304L / 304H Long Radius Bends has general purpose applications in boilers, condensers, oil and gas industries, shipbuilding, power plants, paper, etc. Stainless Steel 304 / 304L / 304H Pipe bends care commonly used pipe bend grades and contains 8% Nickel & 18% Chromium. These Stainless Steel 304 / 304L / 304H Pipe bends are manufactured with a low carbon content that renders exceptional formability and weldability, annealed and fabricated to enhance better performance, high strength. The sizes range depending on seamless (1/2”- 24”), Welded, Fabricated pipe bends (2”-36”). Also, the bend radius (R) varies from 1D to 10D and bending angle 1, 30, 45, 60, 90, 135, 180°. The product conforms to grades like ASME/ASTM B16.9/16.28.
Bullion Pipe offers a wide quality range of these Stainless Steel 304 / 304L / 304H Long radius Bends such as Welded Pipe Bend, Stainless Steel Hot Induction Bend, 3D Pipe Bend, Stainless Steel Piggable Bend, U Pipe Bend, Long Radius Bend, Stainless Steel J Pipe Bend, Mitered Pipe Bend, Seamless Pipe Bend, etc.
Countries We Deliver
Saudi Arabia, Iran, Iraq, UAE, Qatar, Bahrain, Oman, Kuwait, Turkey, Yemen, Syria, Jordan, Cyprus, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, USA, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, Uk, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, India, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Myanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, New Zealand, Romania, Puerto Rico, Nepal, Kenya, Afghanistan, Lithuania, Belarus, Zimbabwe
Cities We Deliver
Indore, Kuala Lumpur, Al Jubail, Pimpri-Chinchwad, Sharjah, Karachi, Chandigarh, Bogota, Muscat, Madrid, Tehran, Granada, Jakarta, Los Angeles, Rio de Janeiro, Melbourne, Cairo, New York, Busan, Milan, Montreal, Singapore, Sydney, Dubai, Lagos, Gurgaon, Port-of-Spain, Hong Kong, Navi Mumbai, Secunderabad, Bangkok, Aberdeen, Bhopal, Atyrau, Caracas, Jamshedpur, Thane, Faridabad, Ahvaz, Ahmedabad, Hanoi, Bengaluru, Dallas, Moscow, Surat, Riyadh, Rajkot, Al Khobar, Hyderabad, Haryana, Ernakulam, Gimhae-si, Algiers, Thiruvananthapuram, Brisbane, Calgary, Mumbai, Chennai, Courbevoie, Toronto, Vung Tau, Ankara, Doha, Nagpur, Howrah, Ranchi, Perth, Noida, Houston, Kolkata, Chiyoda, Mexico City, Edmonton. Geoje-si, Abu Dhabi, Santiago, New Delhi, Colombo, Ludhiana, Lahore, Coimbatore, Ho Chi Minh City, Manama, Ulsan, London, Visakhapatnam, Jaipur, Kuwait City, Seoul, Istanbul, Pune, Baroda, Kanpur, La Victoria, Jeddah, Dammam, Petaling Jaya, Nashik, Vadodara.
Stainless Steel 304/ 304L/ 304H Long Radius Bends
Dimensions : ASME/ANSI B16.9 / B16.28 and MSS SP-43 / SP-75
Size : Seamless Pipe Bends (1/2″ – 24″), ERW / Welded / Fabricated Pipe Bends (2″ – 36″)
Outer Diameter : 38.0 mm – 206.0 mm
Wall Thickness : 1.5 mm / 2.0 mm / 3.0 mm – greater wall thickness at request
Bend Radius : 75 / 100 / 150 / 250 / 300 / 500 / 800 / 1,000 / 1,200 / 1,500 mm
Bending Radius(R): R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Bending angle (θ): 15°, 30°, 45°, 60°, 90°, 135°, 180°
304/304L/304H Stainless Steel Long Radius Bends Chemical Composition:
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
304 | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
304L | min. | – | – | – | – | – | 18.0 | – | 8.0 | 8.0 |
max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | – | 20.0 | ||
304H | min. | 0.04 | – | – | – | – | 18.0 | – | 8.0 | 8.0 |
max. | 0.10 | 2.0 | 0.75 | 0.045 | 0.75 | 20.0 | – | 20.0 |
Stainless Steel 304/304L/304H Long Radius Bends Mechanical Properties:
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
304 | 515 | 205 | 40 | 92 | 201 |
304L | 485 | 170 | 40 | 92 | 201 |
304H | 485 | 205 | 40 | 92 | 201 |
Equivalent Grade of SS 304/304L/304H Long Radius Bends:
STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS |
SS 304 | S30400 | 1.4301 | Z7CN18-09 | X5CrNi18-10 | SUS 304 | 304S31 |
SS 304L | S30403 | 1.4306 | Z3CN18-10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 |
SS 304H | S30409 | 1.4301 | – | – | – | – |
